Established in 2017, we are a China-based company engaged inmanufacturing and supplying of 13 Ton Outboard American Type Trailer Axle. It is well designed at our state-of-the-art facility and fabricated under proper guidance and supervision of deft professionals. These axles are widely used in trolleys and other vehicles to support loads. We have a dedicated team of quality analysts who check 13 Ton Outboard American Type Trailer Axle on various quality parameters prior to dispatch to ensure that our clients get a flawless range.
Features:
Very high strength and durability
Excellent dimensional accuracy
Able to withstand high temperatures
| Axle model | JZ13AWR1 | JZ13AWR2 | JZ13AWS1 | JZ13AWS2 | JZ13AWS3 | JZ13AWS4 | JZ13AWS5 | JZ13AWS6 |
| Rated loading capacity (kg) | 13000 | 13000 | 13000 | 13000 | 13000 | 13000 | 13000 | 13000 |
| Bearing | HM518445/10 | HM518445/10 | HM518445/10 | HM518445/10 | HM518445/10 | HM518445/10 | HM518445/10 | HM518445/10 |
| Wheel track (mm) | 1840 | 1840 | 1840 | 1840 | 1840 | 1840 | 1840 | 1840 |
| Brake size (mm) | 420180 | 420180 | 420180 | 420180 | 420180 | 420180 | 420180 | 420220 |
| Center distance of brake chamber (mm) | 390 | 390 | 390 | 390 | 390 | 390 | 390 | 346 |
| Wheel fixing (P.C.D.H , mm) | 285.75221 | 335281 | 285.75221 | 335281 | 285.75221 | 285.75221 | 335281 | 335281 |
| Wheel bolt size | 8-M201.5 JAP | 10-M221.5 ISO | 10-M201.5 JAP | 10-M221.5 ISO | 10-M201.5 JAP | 10-M221.5 ISO | 10-M221.5 ISO | 10-M221.5 ISO |
| Axle tube (mm) | 127 | 127 | 127 | 127 | 150 | 150 | 150 | 150 |
| Weight (kg) | 350 | 351 | 340 | 339 | 368 | 365 | 365 | 365 |
| Recommended wheel | 7.50V-20 | 7.50V-20 | 7.50V-20 | 7.50V-20 | 7.50V-20 | 7.50V-20 | 7.50V-20 | 7.50V-20 |
| Max. length (mm) | 2198 | 2198 | 2198 | 2198 | 2198 | 2198 | 2198 | 2208 |






Price:
Price 450 USD ($) / Set
Minimum Order Quantity : 20 Sets
Product Type : axle
Color : Black
For Use In : semi trailer truck
Material : Steel
Price 665.0 USD ($) / Set
Minimum Order Quantity : 1 Set
Product Type : Spoke Wheel Bogie Suspension in Trucks
Color : Customized
For Use In : Truck Trailer
Material : Steel
Price 2000.0 USD ($) / Piece
Minimum Order Quantity : 1 Piece
Product Type : Trailer ,Semitrailer and Truck
Color : Black
For Use In : Heavy Duty Truck, Trailer ,Semi Trailer
Material : Steel
Price 100 USD ($) / Piece
Minimum Order Quantity : 58 Pieces
Product Type : Trailer ,Semitrailer and Truck
Color : Black
For Use In : Heavy Duty Truck, Trailer ,Semi Trailer
Material : Steel
